Description
Spraying parameters
Spraying bar hydraulically extended up to 5 m
Equipped with a hand lance
Spraying efficiency from 0.1 to 2.55 kg/sq m
Automatic control of spraying performance depending on the sprayer speed
Automatic cleaning of the spray bar after every spraying
Emulsion tank
3 000 – 5 000 – 6 000 – 8 000 – 10 000 – 12 000 l (depending on type)
CLEAN PUMPING – system of non filtered absorption of pure emulsion by the pump
Filling by own pump or by top filling
Control and reports
Intuitive desktop with colour 12” touch panel in the driver’s cab
Automatic, intuitive control minimising the risk of operator mistakes (without manual valves)
CCTV system for the bar during spraying
Records of every spraying in memory with the possibility to print it out on an in-built printer.
Emulsion heating system
One of the most efficient systems available on the market
Automatic maintenance of the emulsion operating temperature
Supports internal power supply of AC 230 V 50 Hz
Emulsion pump
Rotary displacement pump dedicated for bitumen emulsions
EASY START system– automatic heating supporting the pump start-up
Components’ drive
The Customer may choose from a PTO attachment or own Perkins diesel engine
3-cylinder, liquid cooled with a power of 44 HP
Selected additional equipment
Technical water tank with 140 l/min pump
Lime slurry tank with spraying system
Pressure washer for easier cleaning of the machine
Additional heating systems
Front brush – sweeper
